Woodpecker iLED II Dental LED Curing Light Lamp 1S Curing Metal Head 3000mW/cm²

Woodpecker iLED II Dental LED Curing Light Lamp 1 Sec Curing Metal Head 3000mW/cm²

Power source:

Power supply: rechargeable Lithium battery

Battery mode: 18500

Battery capacity: 2000mAh

Battery has protection against Over-voltage, over-current and short circuit.

Adapter(charge)

Input: 100-240V~ 50/60Hz 0.4A Max.

Output: 5.0V 1A

The adapter must be complies with IEC 60601-1 and IEC 60601-1-2.



Light source:

10W high power blue light LED

Checking method: the LED light is fine when the light is on during operating correctly.

The wave length of this product can match with the clinical dental resin solidification, such as 3M, Dentsply etc.

Wave length: 385nm-515nm

Light intensity: 1000-3000mW/cm2

Working condition

Environment temperature: +5℃ to +40℃

Relative humidity: 30%~75%

Atmosphere pressure: 70kPa to106kPa



Curing light safety:

Operating mode: intermittent operation

Protection type against electrical shock: class Ⅱ.

Protection degree against electrical shock: type B.

Protection against harmful ingress of water or particular matter: ordinary equipment (IPX0).

Safety in the presence of flammable anesthetic mixture with air, oxygen or nitrous oxide: not suitable under this condition.



Technical specifications

Dimensions: 25mm×25mm×240mm.

Net weight: 278g.

Applied parts of the equipment: Top of main unit, Point cure lens

Duty cycle of the equipment: 20 Sec on/20 Sec off



The components of machine(Packing list):

1.Maint unit *1

2.Top of main unit *1

3.Light hood *1

4.Bathymeter *1

5.Adapter *1

6.Charging base *1

7.Point cure lens *1

8.Disposable sleeve *100

9.Qualified certificate *1

10.Instruction manual *1

11. Warranty card *1；
