Touch Screen Dental Lab Zirconia Ceramic Crowns Oven Automatic Programmable Vacuum Porcelain Furnace

Dental Lab Automatic Programmable Vacuum Porcelain Furnace Zirconia Ceramic Crowns Oven Touch Screen

Features:
●The function of temperature adjustment automatically,ensure the actually temperature error within +/-1.
●Easy to operate,compact size;
●Precision stepper motor drive, the smooth and jitter-free functioning, noise-free,Speed programmable.
●Spiral quartz chamber of furnace
●Temperature adjustment automatically before every firing procedure.
●True color touch screen, the operation is simple and convenient.
●USB port can easily connect to the computer service program.
●Built in 99 program.
●Optical status display.


Specification:
OPERATION：
The velocity of temperature increasing: 200℃/min max. (392°F /minute)
The max temperature: :1200℃ max (2283°F)
The time which can be kept at the max temperature: 2 H Vacuum level:1-101%
ELECTRIC POWER：
Operation range：100-120V 50/60HZ 230V 50/60HZ
Electric current：14.5ampere@110V 7.0ampere@230V
Power：max 1500w
TYPICAL SPECIFICATION：
WXDXH :width 27cm Depth 36cm Height 53cm
Usable measure (firing chamber):：9cm（3.5”）
Net weight：20Kg Weight include the package:23.5Kg
AMBIENT CONDITIONS ：
• Indoor use
• Ambient temperature: 2°C to 40°C
• Relative humidity 80% at 31°C
• Maximum altitude: 1500 m (Special Model:3500m)
• Rated voltage fluctuations must not exceed plus/minus 10% of the rated voltage;



DEVICE IN BOX COMPLETE WITH:
• 1 PHOENIX 7 furnace
• 1 Firing pan
• 1 Connection cable for the mains power supply
• 1 Furnace tweezers
• 1 Repair kit package
