Product Description

VORY CLASS N AUTOCLAVE

1. Based on Europe Class N standard, installed with wrapped and unwrapped system, both of them have the choice on 121 and 134℃

2. Sterilizing were controlled by computer, suitable for the dept of Stomatology, Ophthalmology, Surgery and Lab.

3. With safety system: safety valve, manual door lock, error self-test and overheat protector.

4. The chamber were made by special Stainless Steel #304, working pressure from-0.9bar to 2.3 bar.

5. The bracket installed with 3 sterilizing plate.

6. Quick sterilizing process in 15-30 minutes(depend on the temperature)

Main Features

Sterilization Class C:LASS N

Sterilization Temperature:121°C, 134°C

Sterilization Time:25mins/6mins

Control Precision Temperature:1°C, Pressure: 0.1bar

Tray Rack:5-layer tray rack with 3 trays

Operation Temperature:5-40°C

Water Supply Manually:0.8-1L

Noise:<50db

Water consumption in one cycle:0.2L(min)0.3L(max)

Chamber volume:18L(Φ250×350mm)

packing size:540*430*450mm

Working Pressure/Temperature:1.10~1.30bar/121 ~122 °C°C;2.10~2.30bar/134 ~135 °C°C

Chamber:Medical stainless steel 304, Max working pressure: 2.3bar, Main Working

pressure:-0.9bar, Max temperature: 145°C

Safety System Relief valve(safety valve), Hand lock door, Pressure and temperature over load protection,Aalarm system
